MYG
| Quantity: | |
|---|---|
The MYG 8inch Flap Wheel is a high-performance abrasive tool engineered with a high flexible design, specially crafted for finishing and polishing tasks. It is made from premium anti-high temperature industrial Hand Pads, delivering outstanding cutting effect that stands out among Nylon Non-woven Abrasives. This flap wheel excels in processing uneven workpiece surfaces, enabling metal workpieces to showcase their natural metal texture and achieve a perfect long line finishing effect, such as the wire drawing treatment after electroplating. With customizable specifications, it caters to diverse industrial polishing demands, making it a go-to choice for precision finishing applications.
It is optimized for uneven workpiece surfaces, ensuring consistent polishing without leaving dark points even under high-speed operation, and creates ideal long line finishes for metal workpieces.
Constructed with anti-high temperature industrial Hand Pads, it maintains stable performance at the maximum speed of 3000RPM, featuring excellent wear resistance and a long service life.
It delivers the best finishing result in its category, and can enhance the metal texture of workpieces, meeting the high-quality finishing requirements of electroplating post-processing.
The main body of the flap wheel is made of high cutting effect and anti-high temperature industrial Hand Pads. The inner core material includes phenolphthalein tube as standard, with customizable options of non-woven wheels, plastic tube and aluminium tube to adapt to different application scenarios.
Parameters | Values | Customization |
Outer diameter | 8inch | 7.5CM - 50CM（3inch - 20inch） |
Width | 1inch | 0.5CM - 20CM（0.2inch - 8inch） |
Inner diameter & Materials | Phenolphthalein tube: 25.4mm | Non-woven wheels, Plastic Tube, Aluminium tube |
Grit size | 180# | 46# - 3000# SiC Al2O3 |
Density or hardness | normal | harden |
Color | Grey | Red/Green/Maroon/Brown/Dark Brown |
Speed | 3000RPM | 3000RPM |
Metal Craft Processing: Archaize copper production, mobile phone cases and computer casing polishing, which can enhance the texture and appearance of products.
Watch Industry: Precision polishing of watch components, ensuring smooth and burr-free surfaces.
Decorative Hardware: Finishing of stainless steel workpieces, locks, door handles and other decorating metal ware.
Electrical Appliance Manufacturing: Polishing of electrical appliance parts, improving the surface quality and assembly precision.
Always operate the flap wheel within the rated speed of 3000RPM to avoid safety hazards and performance degradation caused by over-speed operation.
Wear professional protective equipment such as goggles and dust masks during operation to prevent abrasive dust and debris from harming the human body.
Check the integrity of the flap wheel before use. Stop using it immediately if there is any damage such as cracks or shedding.
Fix the workpiece firmly during polishing to avoid vibration affecting the finishing effect or causing workpiece slipping.
Can the grit size of the flap wheel be customized according to my processing requirements?
Yes, we support grit size customization ranging from 46# to 3000# with SiC and Al2O3 materials, which can meet the needs of rough grinding to fine polishing.
Is this flap wheel suitable for wooden workpiece polishing?
Absolutely. It is not only suitable for metal workpieces but also can be used for polishing wooden workpieces and varnish, with a good finishing effect.
How to choose the right inner core material?
Phenolphthalein tube is suitable for general scenarios. Non-woven wheels are more flexible, plastic tubes are lightweight, and aluminium tubes have higher rigidity. You can choose according to your equipment and workpiece characteristics.
Are you looking for a high-performance flap wheel that can handle uneven surfaces and achieve excellent long line finishes? The MYG 8inch Flap Wheel is your ideal choice. Click the "Inquire" button to get a detailed quotation, or directly "Add to Basket" to place your order. Our professional team will provide you with thoughtful pre-sales and after-sales service to solve all your polishing problems.
