MYG
| Quantity: | |
|---|---|
The Non-Woven Handle Grinding Head is a high-performance minitype abrasive tool designed for hand polishing machines. It delivers the same premium grinding characteristics as standard non-woven abrasive materials, and it is especially tailored for scenarios where large polishing equipment cannot be easily deployed. This tool stands out with its excellent flexibility and long-lasting durability, making it a go-to choice for precision surface finishing across diverse industries. It is branded as MYG, a reliable option for both small-scale processing and batch production needs. The tool operates stably at high speeds, ensuring consistent results without compromising on workpiece quality.
This grinding head maintains smooth operation even at a high rotation speed of 3000RPM, with zero blockage issues during continuous use. This feature significantly boosts work efficiency and reduces downtime for tool maintenance.
It provides outstanding grinding results and ensures the polished workpiece surface meets strict industry standards for brightness and flatness. The non-woven material design prevents over-grinding and damage to the workpiece surface.
The tool is highly customizable in terms of size, hardness, and color to fit specific application needs. Its robust structure guarantees extended service life, lowering the overall cost of consumables for users.
The Non-Woven Handle Grinding Head is primarily made of high-quality non-woven abrasive fibers. These fibers are bonded with advanced resin binders to form a flexible yet sturdy grinding layer. The handle part is crafted from wear-resistant engineering plastic, ensuring a firm connection with the hand polishing machine spindle and comfortable operation for users. The material combination balances flexibility and grinding efficiency, suitable for both metal and non-metal surface treatment.
Parameters | Default Value | Customization Options |
Outer Diameter | 40mm | 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 80mm, 100mm |
Width | 25mm | 12mm, 15mm, 25mm, 38mm, 50mm |
Spindle Size | 6mm | 3mm, 6mm |
Grit Size | 180# | 46# - 200# |
Density or Hardness | 7P | 5P, 9P, 12P, etc. |
Color | Grey | Brown/Maroon/Red/Green |
Speed | 3000RPM | 3000RPM |
It is ideal for polishing plane parts and auto components, delivering a smooth surface that meets automotive industry quality requirements.
The tool works perfectly for grinding stainless steel kitchen utensils, tableware, knives, forks, and vacuum flasks, enhancing their surface brightness and texture.
It is suitable for polishing building metal hardware, including handles, hinges, and locks, improving both appearance and corrosion resistance.
It can be used for surface treatment of metal watchbands, lamps, and golf rackets, ensuring fine and uniform surface finishing.
It is applicable for polishing woodenware, plastic wares, and marble, without causing cracking or surface damage to these materials.
Operators must wear safety goggles and dust masks during use to prevent abrasive dust and debris from entering the eyes and respiratory tract.
Do not exceed the maximum speed limit of 3000RPM, as over-speed operation may lead to tool damage or safety hazards.
Before installation, confirm that the machine spindle size matches the grinding head’s spindle size to avoid unstable operation during use.
Store the grinding head in a dry and ventilated environment to prevent moisture from affecting the abrasive performance.
Yes, the grit size can be customized within the range of 46# to 200#. You can choose the appropriate grit size according to your polishing precision requirements.
The hardness is available in 5P, 7P, 9P, 12P, etc. For soft materials like plastic, choose lower hardness (5P - 7P); for hard metals like stainless steel, select higher hardness (9P - 12P).
It is mainly designed for hand polishing machines, but it can also be used on semi-automatic polishing machines with matching spindle sizes.
Are you looking for a flexible and durable abrasive tool for precision polishing? Contact us now to inquire about the Non-Woven Handle Grinding Head! We offer customized solutions to meet your specific processing needs. Add the product to your basket today and enjoy high-quality surface finishing results with low cost!
